Asahi/America Inc.
QM Remote Cycle
Asahi/America, Inc., the leader in fluid flow solutions, introduces the Quarter Master (QM) Remote Cycle™. A complete QM Remote Cycle™ unit consists of an Asahi/America Series 94 electric actuator with self-powered battery and open/close timer mounted to a ball or butterfly valve for use in remote areas where power sources are limited or unavailable.
Asahi's QM Remote Cycle™ features a NEMA 4X engineered resin enclosure with stainless steel trim, on/off switch, adjustable open and interval times via dip switches, and manual override. The QM Remote Cycle's™ 12vdc rechargeable battery can cycle 1,100 times, once fully charged.
The QM Remote Cycle™ and Series 94 quarter-turn actuator can be mounted to Asahi/America Type-57 butterfly valves (sizes 1 1/2" – 4") and Type-21 ball valves (sizes 1/2" – 2"). Asahi/America's QM Remote Cycle™ unit provides continuous and reliable cycling in remote mining, chemical, water, and wastewater applications.
Asahi/America, Inc., 35 Green Street, Malden, MA 02148, toll-free 800-343-3618 or 781-321-5409, fax 800-426-7058, asahi@asahi-america.com.
