EXAIR Co.
PEEK Super Air Nozzle
EXAIR’s PEEK 3/8 NPT Super Air Nozzle features protective aerodynamic slots that guide the airflow to a single point of convergence for hard-hitting force and dramatic noise reduction over typical blowoffs. Its PEEK plastic construction provides non-marring protection to production items and excellent resistance to damage from harsh chemicals and it operates in temperatures up to 320°F (160°C). The nozzle is suitable for blowoff, cooling and drying applications located in general industrial or corrosive environments.
The Model 1104-PEEK 3/8 NPT Super Air Nozzle provides a strong blowing force. High amplification of airflow produces a blowing force of 1.9 pounds (850 grams), with air consumption of only 35 SCFM at 80 PSIG. Safe operation is assured since the airflow of the CE compliant Super Air Nozzle cannot be blocked, which meets OSHA dead-end pressure standard 29 CFR 1910.242(b). Sound level is very low at 82 dBA and meets OSHA noise requirement 29 CFR 1910.95(a).
The 1104-PEEK Super Air Nozzle is designed to easily replace existing wasteful nozzles or open pipes. The 3/8 NPT Super Air Nozzle is also available in Type 316 Stainless Steel and Zinc Aluminum alloy. Other PEEK thermoplastic air nozzles are available in M4x.05, M5x.05, M6x.075, 1/8 NPT and 1/4 NPT thread sizes.
